Description
Outer diameter
– from 0.04“ (1,0 mm) up to 0.99” (25,0 mm)
Flat cable
– up to 1.38“ (35,0 mm) width
Stripping length *
– up to 4.73” (120,0 mm)
Partial stroke
– up to 9.85” (250 mm)
* Full stroke
Variants:
– with pneumatic sensor
– with light barrier
Optional Devices:
– Slitting device for slitting and stripping flat cables
– Special blade head constructions for graduated or 2step processing (tests and construction are necessary in our company)
– Stripping stop dog for greater stripping length (partial stripping)
– stroke limitation for partial stripping and quicker working
– Pneumatic sensor
– Light barrier for very precise stripping results
Specifications
Type | |
---|---|
Length (mm) | |
Width (mm) | |
Height (mm) | |
Compressed air | |
Min. Cross-section (mm²) | |
Max. outside diameter (mm) | |
Inner conductor processing | |
Dual Head | |
Slit unit | |
Coax processing |
