Beschrijving
Dismantling of cables with outer diameter of 3.5 to 11.9 mm
Electropneumatic control system
Application of quadruple star blades for different cable diameters
The star blade includes following sizes:
– V-Radium 3.49 mm
– V-Radium 4.37 mm
– V-Radium 6.20 mm
– V-Radium 7.70 mm
Easily adjustable dismantling and pull – off length between 25 and 115 mm
Easy changing of V – Radium blades without knife exchange
Compact construction and light weight
Specifications
Type | Strip |
---|---|
Length (mm) | 254 |
Width (mm) | 230 |
Height (mm) | 520 |
Weight (kg) | 17 |
Power | 240 VAC /50Hz / 60Hz |
Compressed air | yes |
Max. outside diameter (mm) | 11.9 |
Inner conductor processing | No |
Dual Head | No |
Slit unit | No |
Coax processing | No |
