Z+F – Crimping Machine PCM
Beschrijving
In the range of 0.08 up to 4 mm2 (AWG 28 – 12) wires and contacts can be crimped.
A 4/8-indent crimp corresponding to SAE 22520 is standard. The crimping-depth can be adjusted manually in 10 µm steps.
The machine is equipped with standard crimping tool kit, the crimper can be easily adapted to various contacts. Brackets for optimized infeed and centering of the wire are optionally available.
Options
– Other crimp form: 4-indent
– Brackets for optimized infeed and centering of the wire
Specifications
Type | Crimp |
---|---|
Depth (mm) | 260 |
Width (mm) | 140 |
Height (mm) | 210 |
Weight (kg) | 8 |
Compressed air | yes |
